MSG 2016 – Spring 2017 Signal Chain

The signal chain (starting MSG 2016-17) was as follows:

Languedoc Guitar –> Dunlop GCB-95 Wah –> Custom Audio Electronics 4X4 switchers (loops 1-8 below) –> Komet Trainwreck 60 amps.

Loop #1: Digitech Whammy 2 / Beigel Tru-Tron 3X
Loop #2: Klon
Loop #3: Ibanez TS-808 “less” distortion
Loop #4: Ibanez TS-808 “more” distortion
Loop #5: Alesis Microverb
Loop #6: Shin Ei Univibe
Loop #7: Boomerang Phrase Sampler ver 1. / Ibanez DM-2000 digital delay
Loop #8: Way Huge Supa Puss analog delay

The above is confirmed by the photos below, the first of which is Riviera Maya 2017 and the second is MSG NYE 2016-17:

In the above MSG picture, you can see the signal chain pretty clearly laid out, although the order is confusing.  There are three rows of buttons, with the top row having four and the other two rows having three, as follows:

1 WHAMMY/MU — 7 BOOM/DM2000 — MOD (DM2000) — HOLD (DM2000)

4 MORE — 6 UNIVIBE — 5 MICRO

2 KLON — 3 LESS — 8 PUSS
